Frame camera configuration

Required camera model parameters are read from file. Additional command line options allow configuration of frame camera model behaviour, via the oty frame, oty exif or oty odm sub-commands.

The --full-remap option configures a camera to remap the source to ortho image in one step. This uses the full model including distortion, and is the default behaviour. With --no-full-remap, the source is first remapped to an undistorted image, then remapped to the ortho image using a pinhole model excluding distortion. --no-full-remap is faster, but can use more memory and reduce ortho quality, as it remaps and interpolates twice.

The --alpha option can be supplied with --no-full-remap to specify the scaling of the undistorted image. An --alpha value of 0 scales the undistorted image so that all its pixels are valid. An --alpha value of 1 (the default) scales the undistorted image so that it includes all source pixels. The plot below illustrates this for --alpha values of 0 and 1:

To show the use of these options, we orthorectify the OpenDroneMap dataset using the --no-full-remap option with an --alpha value of 0:

oty odm --dataset-dir odm --no-full-remap --alpha 0

Note

The --full-remap / --no-full-remap and --alpha options have no effect for pinhole camera models.
